Power Supply Power Class Output Voltage Output Current Input Voltage Type of Housing Cooling Method Qualification Size (mm) Others 20W 12kV 1.6mA 230VAC @ 50Hz Open Frame Convection UL Certified 280 x 110 x 35 140W - 250W 24V/5.3V/15V/10V 6.5A/9.9A/0.6A/0.5A 230VAC @50Hz Open frame Convection EN60065/EN55013/EN61000 240 x 197 x 19.6 - 1080W DC / 3200W AC 5V - 40VDC (5 DC outputs) / 230VAC (3 AC outputs) 2.5ADC - 18ADC / 14AAC 180VAC - 255VAC @48Hz - 62Hz Galvanized metal sheet Fan cooled CB Report 410 x 278 x 73 -
LED Driver Power Class Output Voltage Output Current Input Voltage Type of Housing Cooling Method Qualification Size (mm) Others 42W 25V - 60V 0.7A - 1.68A 230VAC @50Hz Closed frame Convection CE 244 x 65 x 46 DALI optional 70W 25V - 60V 1.16A - 2.8A 230VAC @50Hz Closed frame Convection CE 244 x 65 x 46 DALI optional
| Power Class | Output Voltage | Output Current | Input Voltage | Type of Housing | Cooling Method | Qualification | Size (mm) | Others | |
|---|---|---|---|---|---|---|---|---|---|
| 20W | 12kV | 1.6mA | 230VAC @ 50Hz | Open Frame | Convection | UL Certified | 280 x 110 x 35 | ||
| 140W - 250W | 24V/5.3V/15V/10V | 6.5A/9.9A/0.6A/0.5A | 230VAC @50Hz | Open frame | Convection | EN60065/EN55013/EN61000 | 240 x 197 x 19.6 | - | |
| 1080W DC / 3200W AC | 5V - 40VDC (5 DC outputs) / 230VAC (3 AC outputs) | 2.5ADC - 18ADC / 14AAC | 180VAC - 255VAC @48Hz - 62Hz | Galvanized metal sheet | Fan cooled | CB Report | 410 x 278 x 73 | - |
| Power Class | Output Voltage | Output Current | Input Voltage | Type of Housing | Cooling Method | Qualification | Size (mm) | Others | |
|---|---|---|---|---|---|---|---|---|---|
| 42W | 25V - 60V | 0.7A - 1.68A | 230VAC @50Hz | Closed frame | Convection | CE | 244 x 65 x 46 | DALI optional | |
| 70W | 25V - 60V | 1.16A - 2.8A | 230VAC @50Hz | Closed frame | Convection | CE | 244 x 65 x 46 | DALI optional |
